Introducing the public API

Overview

Zato uses 160+ internal services for controlling most aspects of running a cluster, such as creating new connection definitions, updating statistics, configuring passwords and so on.

Most of the services are available through Zato’s public API in both SOAP and JSON via HTTP. It is possible to use the services exposed for creating external applications that assume the roles of what is typically performed by the web admin. These could be anything ranging from custom iPhone applications through Java clients to simply invoking the services from curl.

Message format

A service always has request and response documents defined. Being written using SimpleIO (SIO), these can be either SOAP or JSON. For each response document, there is always a technical envelope - called zato_env - defined and optionally, the actual business payload users are mostly interested in.

The payload can be either a single item or a list of items. For instance, fetching an AMQP connection’s details will return the former while asking for a list of servers a particular service is deployed on will yield the latter.

The general format has been illustrated below, note that the zato_env element is always returned at the same position while the actual content differs each time. Also note that for JSON, the request element is omitted and request parameters can be passed in directly - there is no ‘zato_get_foo_request’ key to wrap all the input parameters with even though the response uses one, such as ‘zato_get_foo_response’ and ‘zato_get_bar_list_response’ in examples below.

Refer to the documentation of each of the services to learn more about particular elements returned.

SOAP

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"
     xmlns:zato="https://zato.io/ns/20130518">
   <soapenv:Header/>
   <soapenv:Body>
      <zato:zato_get_foo_request>
        <zato:req_elem1>...</zato:req_elem1>
        <zato:req_elem2>...</zato:req_elem2>
        ...
        <zato:req_elem_n>...</zato:req_elem_n>
      </zato:zato_get_foo_request>
   </soapenv:Body>
</soapenv:Envelope>

<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/"
     xmlns="https://zato.io/ns/20130518">
   <soap:Body>
      <zato_get_foo_response>
         <zato_env>
            <cid>K21353002988419985838198535608</cid>
            <result>ZATO_OK</result>
         </zato_env>
         <item>
            <resp_elem1>...</resp_elem1>
            <resp_elem2>...</resp_elem2>
            ...
            <resp_elem_n>...</resp_elem_n>
         </item>
      </zato_get_foo_response>
   </soap:Body>
</soap:Envelope>
<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/"
     xmlns:zato="https://zato.io/ns/20130518">
   <soapenv:Header/>
   <soapenv:Body>
      <zato:zato_get_bar_list_request>
        <zato:req_elem1>...</zato:req_elem1>
        <zato:req_elem2>...</zato:req_elem2>
        ...
        <zato:req_elem_n>...</zato:req_elem_n>
      </zato:zato_get_bar_list_request>
   </soapenv:Body>
</soapenv:Envelope>

<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/"
     xmlns="https://zato.io/ns/20130518">
   <soap:Body>
      <zato_get_bar_list_response>
         <zato_env>
            <cid>K37683756065213515208747449888</cid>
            <result>ZATO_OK</result>
         </zato_env>
         <item_list>
            <item>
               <resp_elem1>...</resp_elem1>
               <resp_elem2>...</resp_elem2>
               ...
               <resp_elem_n>...</resp_elem_n>
            </item>
            <item>
               <resp_elem3>...</resp_elem3>
               <resp_elem4>...</resp_elem4>
               ...
               <resp_elem_j>...</resp_elem_j>
            </item>
         </item_list>
      </zato_get_bar_list_response>
   </soap:Body>
</soap:Envelope>

JSON

{
  "req_elem1":"...",
  "req_elem2":"...",
  ...
  "req_elem_n":"...",
}

{
  "zato_env": {
    "details": "",
    "result": "ZATO_OK",
    "cid": "K68938864847262437323255781583"
  },
  "zato_get_foo_response": {
    "resp_elem1": "...",
    "resp_elem2": "...",
    ...
    "resp_elem_n": "..."
  }
}
{
  "req_elem1":"...",
  "req_elem2":"...",
  ...
  "req_elem_n":"...",
}

{
  "zato_env": {
    "details": "",
    "result": "ZATO_OK",
    "cid": "K28185890067723564136752725554"
  },
  "zato_get_bar_list_response": [
    {
      "resp_elem1": "...",
      "resp_elem2": "...",
      ...
      "resp_elem_n": "..."
    },
    {
      "resp_elem3": "...",
      "resp_elem4": "...",
      ...
      "resp_elem_j": "..."
    }
  ]
}

Conventions

There are only few conventions to understand before making use of the Zato public API

  • All messages always need to be in UTF-8. Zato never uses any other encoding.
  • All date and datetime objects are always in UTC. Internally, Zato servers never use any other time zone thus one always needs to convert the user input from their local TZ to UTC.
  • All .create and .edit actions always copy over the 'id' and 'name' parameters from request to response.
  • All passwords are always sent in clear-text.

zato_env

zato_env is a technical envelope carrying useful information in each response. It is available if the service has been successfully invoked and can be used, for instance, for correlating responses received by clients with messages written out to Zato server logs.

zato_env elements

Name Datatype Optional Notes
cid string --- Unique 96-bit correlation ID assigned to this message exchange, always 29 characters long and always starts with the letter 'K'
result string --- Can be one of ZATO_OK, ZATO_ERROR or ZATO_WARNING. ZATO_OK means a successful service invocation.
details string Yes ---

Reporting exceptions

SOAP channels use SOAP-ENV:Fault elements for reporting unexpected exceptions caught during the execution of a service:

 <?xml version='1.0' encoding='UTF-8'?>
 <SOAP-ENV:Envelope
   xmlns:SOAP-ENV="http://schemas.xmlsoap.org/soap/envelope/"
   xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance"
   xmlns:xsd="http://www.w3.org/1999/XMLSchema">
    <SOAP-ENV:Body>
      <SOAP-ENV:Fault>
      <faultcode>SOAP-ENV:Client</faultcode>
 <faultstring><![CDATA[cid [K68438211212681798524426103126], faultstring
 [Traceback (most recent call last):
File
"/opt/zato/code/zato-server/src/zato/server/connection/http_soap/
channel.py", line 126, in dispatch
  service_info, response = handler.handle(cid, wsgi_environ, payload, transport,
  worker_store, self.simple_io_config, data_format, path_info)
File
"/opt/zato/code/zato-server/src/zato/server/connection/http_soap/
channel.py", line 227, in handle
  service_instance.handle()
File
"/opt/zato/code/zato-server/src/zato/server/service/internal/
definition/amqp.py", line 174, in handle
  filter(ConnDefAMQP.id==self.request.input.id).\
File
"/opt/zato/code/eggs/SQLAlchemy-0.7.9-py2.7-linux-x86_64.egg/sqlalchemy/
orm/query.py", line 2190, in one
  raise orm_exc.NoResultFound("No row was found for one()")
NoResultFound: No row was found for one()
]]]></faultstring>
       </SOAP-ENV:Fault>
   </SOAP-ENV:Body>
 </SOAP-ENV:Envelope>

JSON responses use zato_env. Note that the 'details' element below still contains a traceback, it's only a lack of multiline-strings in JavaScript that forces Zato to return it as a single line:

{
  "zato_env": {
    "details": "Traceback (most recent call last):\n  File \"\/opt\/zato\/code\/zato-server\/src\/zato\/server\/connection\/http_soap\/channel.py\", line 142, in dispatch\n    service_info, response = handler.handle(cid, wsgi_environ, payload, transport, worker_store, self.simple_io_config, data_format, path_info)\n  File \"\/opt\/zato\/code\/zato-server\/src\/zato\/server\/connection\/http_soap\/channel.py\", line 252, in handle\n    service_instance.handle()\n  File \"\/opt\/zato\/code\/zato-server\/src\/zato\/server\/service\/internal\/definition\/amqp.py\", line 174, in handle\n    filter(ConnDefAMQP.id==self.request.input.id).\\\n  File \"\/opt\/zato\/code\/eggs\/SQLAlchemy-0.7.9-py2.7-linux-x86_64.egg\/sqlalchemy\/orm\/query.py\", line 2190, in one\n    raise orm_exc.NoResultFound(\"No row was found for one()\")\nNoResultFound: No row was found for one()\n",
    "result": "ZATO_ERROR",
    "cid": "K47568862487942557263894250839"
  }
}
